150 Amp Petrol Welding Generator, 5 KVA AC Output, Recoil Start, Model: HPW-5000-TIG

( 2 Reviews )

₹106814 ~~₹138858~~

9412918664 9412052496

Welding Output Current (Duty Cycle60%) : 150Amps.
Welding Output Current (Duty Cycle100%): 120Amps.
Electrode diameter : 1.6 mm to 3.2 mm
Max AC Output (Single Phase) : 5000 VA
Starting System : Recoil Start
Fuel Consumption Ltr./Hr. : 1.5 Ltr./hr. (Approx)
Continuous Operating Hour : Approx. 15 hr.

Special Highlights & Applications

Most suitable for Low Current & medium Current Welding of thin Sheets, Arc Welding (MMA) on MS Sheets / Parts, Argon Welding (TIG) on SS Sheets / Parts
Generator 5 KVA - AC 230 V, 50 Hz Output for Running AC Appliances

This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Qty:

Product Information

Type: DC Welder MMA / TIG Welder Cum AC Generator
Rated Welding Current Duty Cycle (40⁰C 10 Min) : 60 % 150A ,100% 120 A
Working Voltage :18v to 25 v
No Load Voltage (V) : 56
Welding Current Range(A): 10-150
Electrode Día (for Arc Welding) : 1.6 mm to 3.2 mm
Protection Class : Ip23
Insulation Class : H
Cooling : Forced Air Colling

AC Generator

AC Generator : GE 5000 R
*Max AC. Output VA : 4200 / (5000 @ 60 Hz)
*Rated AC. Output VA : 3900 / (4400 @ 60 Hz)
Rated Current Amps : 18
NFB Amps : 19
AC. Voltage at No Load : 250 Volts ± 5 Volt ,50 / 60 Hz, Single Phase
AC. Voltage at Rated Load : 220 volt ± 10 Volts

Alternator

#Alternator Max. Current Capacity : 24 Amps.
Alternator : Brushless, Rare Earth Magnetic Rotor, THD ≤5 %, Pure Sine Wave

Engine

Model : HM170 P
Type : OHV25°Inclined, Single Cylinder,4 Strokes, S.I, Forced Air Cooling
Maximum Power : 7.5 HP @ 3600
Bore x Stroke : 70x58 mm
Displacement : 223cc
Starting System : Recoil Start
Fuel : Petrol
Fuel Tank Capacity : Petrol - 21.0 Ltr.
Fuel Consumption : Petrol: 1.5 Ltr./hr.
Continues Running (With One Filling) : 15 Hrs
Lube. Oil Capacity : 600 ml.
Lubricating Oil Consumption : 2.5 gm./Hr.
Sound level (Db) (from 1 meter) : <86Db

Panel & Other Standard Features

Voltmeter : Yes (Analogue)
Digital Hour Meter : No
Oil Alert System : Yes
LPG/ Gas Fuel Compatibility : No
AMF Panel Auto & Remote Start Compatibility : No
Fuel Level Gauge : Yes
Overload Protection (NFB) : Yes
Costar Wheels & Handle Sets : Yes

Size & Weight

Dimension LxWxH (mm) : 800 x 450 x 615 mm
Gross weight-KG (Approx.) : 78 Kg

Standard Accessories

AC Plug : 1Pec.
Tool Kit : 1 Set
Welder Holder : 1 Set
Tig Welding Torch with Standard Cable length : 1 Set
Earthing Clamp with 3mtr. Cable : 1 Set
Oil Funnel : 1 No.
Owner’s Manual: 1 No.

Warranty

Warranty Summary	*1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier
Service Type	Authorized Service Center or on Site by Visiting Service Engineer as Per Nature of Complaint
Covered in Warranty	*1 Year or 500 hrs standard manufacturing warranty on Engine and Alternator whichever is earlier
Not Covered in Warranty	NO WARRANTY ON PHYSICAL DAMAGES, ANY OF THE ELECTRONIC SPARES IN GENERATOR, AND EVERY DAY USABLE ITEM.
